No Heating Cable Required
System B uses a pressurized Air Tank to purge water from the supply line below ice level. It does not require the use of a short piece of Heating Cable at the water source.
Ideal for Solar or Off-Grid Cottages
Since there is no heating cable required, this system is a good choice for cottages that are off-the-grid.
Proven
We have over 20 years experience specializing in cottage water systems with customers throughout Canada and the U.S.
Patented*
Our self-draining systems use patented, specially-designed valves to automatically drain the supply line, keeping the line from freezing during the winter.
How Does Self-Draining System B Work?
- The Submersible Pump turns on and pushes water up to the cottage.
- Air from the empty Supply Line escapes through the Self-Draining Air Valve into the Air Tank. The Pressure Tank fills with water.
- Once the Pressure Tank is full of water, the Pump shuts off and the Supply Line automatically drains back to the lake.
- The pressurized Air Tank purges the Supply Line below ice level. Because the line remains empty it does not need to be protected from freezing.
A Complete System Package Includes**:
![](https://www.cottagewatersupply.com/wp-content/uploads/2016/12/Submersible-Pump-1.0.png)
Submersible Pump
Goulds CS Series stainless steel or Pompco ST stainless steel
![](https://www.cottagewatersupply.com/wp-content/uploads/2016/12/Water-Pressure-Tank-1.0.png)
Water Pressure Tank
Goulds HydroPro Series
![](https://www.cottagewatersupply.com/wp-content/uploads/2016/12/Self-Draining-Valves-1.0.png)
Self-Draining Valve Kit Assembly
Cottage Water Supply patented valves
![](https://www.cottagewatersupply.com/wp-content/uploads/2017/03/Tank-Tee-A-2.0.png)
Tank Tee Assembly
Customized and fully assembled. Brass, stainless steel and copper fittings.
![](https://www.cottagewatersupply.com/wp-content/uploads/2017/03/Air-Tank-1.0.png)
Air Tank
Pressurized air tank to purge the supply line below ice level.
![](https://www.cottagewatersupply.com/wp-content/uploads/2016/12/Poly-Pipe-1.0.png)
Poly Pipe
1″ heavy duty 100 PSI CSA poly pipe
![](https://www.cottagewatersupply.com/wp-content/uploads/2016/12/Pump-Cable-1.0.png)
Pump Cable
#12 or #10 pump cable
![](https://www.cottagewatersupply.com/wp-content/uploads/2016/12/Pump-Stand-1.0.png)
Pump Stand
Cottage Water Supply custom-designed submersible pump stand.
Hot-dip galvanized steel with PVC sleeve.
System Requirements
- Constant slope from the cottage to the water source — no dips or valleys
- Minimum rise:run of 1:10
- Minimum water depth of 7’ for placement of the pump in the lake
Does your cottage have different requirements?
We can always find a custom solution for you. Give us a call: 416-255-8087
**Systems are customized. Actual components may vary.
