Three-Season Water Systems

CWS Header Image

The Right System for Your Cottage

Whether you are looking for a standard Jet Pump, a modern Self-Priming Jet Pump, or a low-maintenance Submersible Pump, we have the perfect water system for you.

Custom Solutions

All of our system packages are customized to provide the right cottage water system for your needs.

Durable & Reliable

All of our water systems are built using quality components, chosen for value, performance and durability.

Quality Components

Goulds pumps and tanks are top-of-the-line, made in USA and Canada. Pompco pumps are well-built, good value, made in Canada. Systems are assembled using brass, copper and stainless steel fittings.

Low Maintenance

We pride ourselves on providing our customers with reliable systems designed for years of trouble-free use.

Startup & Winterization

Our water systems are designed with easy start-up and winterization in mind.

Easy to Install

Our custom DIY packages are designed so anyone who is handy can install. Systems can be configured with quick-connect fittings and pre-wired electrical for a truly plug-and-play setup where no plumber or electrician may be required.

Three-Season Water Systems

Submersible Pump System

Goulds Submersible Pump

System Components*

  • Submersible Pump
    Goulds CS Series, stainless steel
    (Made in USA); or
    Pompco ST, stainless steel
    (Made in Canada)
    1/2 HP and up, 115 or 230 volt**
  • Water Pressure Tank
    Goulds HydroPro Series
    (Made in Canada)
    19.9 gallon and up
  • Tank Tee Assembly
    Three-Season, easy-to-winterize assembly. Customized and fully assembled.
  • Easy Winterization Drain Valve Assembly
  • Pump Stand
  • Poly Pipe
  • Pump Cable

Extended Season Option

Components can be added to extend the season and keep the system running until the lake freezes over. (Not full winterization—see our Self-Draining Winter Water Systems for year-round options.)

Winterization

The simplest, most low-maintenance system. Line and pump does not need to be removed from the lake. Easy Winterization Drain Valve Assembly makes draining the line at the end of the season easy.

Priming

No manual priming required whatsoever. Submersible pumps are fully self-priming. Easiest spring start-up: close drain valves, turn on power to the pump and you have water.

Other Benefits

Higher performance with double the volume of water compared to similar HP jet pumps. Significantly better water pressure. Suitable for any elevation. Almost zero seasonal maintenance.

True Self-Priming Jet Pump System

Goulds J5SH Self-Priming Jet Pump

System Components*

  • Self-Priming Jet Pump
    Goulds J5SH
    (Made in USA)
    1/2 HP, 115 or 230 volt, 6 GPM**
  • Water Pressure Tank
    Goulds HydroPro Series
    (Made in Canada)
    19.9 gallon and up
  • Tank Tee Assembly
    Three-Season, easy-to-winterize assembly. Customized and fully assembled.
  • Quick-Connect Fittings for Pump
    Designed for easy start-up and winterization.
  • In-Lake Intake Strainer
    Standard foot valve is not required with our setup.
  • Poly Pipe

Winterization

Easier than standard jet pump system. Line and intake strainer does not need to be removed from the lake.

Priming

Easy to prime at the beginning of the season. Only a few litres of water are required to create suction and the pump will draw air through itself and self-prime. Not sensitive to air bubbles like a standard jet pump.

Easy-Prime Jet Pump System

Goulds JRS5 Jet Pump

System Components*

  • Jet Pump
    Goulds JRS5H
    (Made in USA)
    1/2 HP, 115 or 230 volt, 5 GPM**
  • Water Pressure Tank
    Goulds HydroPro Series
    (Made in Canada)
    19.9 gallon and up
  • Tank Tee Assembly
  • Quick-connect fittings for pump
    Designed for easy start-up and winterization
  • Foot Valve
  • Poly Pipe

Winterization

Quick-connect fittings for easy winterization. Line and foot valve needs to be removed from the lake.

Priming

Manually primed. (Not a true self-priming pump, but much easier to prime than a standard jet pump. Goulds JRS5H is not sensitive to air bubbles in the line.)

Standard Jet Pump System

Pompco PSW Jet Pump

System Components*

  • Jet Pump
    Pompco PSW-50
    (Made in Canada)
    1/2 HP, 115 or 230 volt, 5 GPM**
  • Water Pressure Tank
    Zilmet (Made in Italy), or
    Amtrol (Made in USA)
    8 gallon and up
  • Tank Tee Assembly
  • Quick-connect fittings for pump
    Designed for easy start-up and winterization
  • Foot Valve
  • Poly Pipe

Winterization

Quick-connect fittings for easy winterization. Line and foot valve needs to be removed from the lake.

Priming

Manually primed.



Goulds Logo
Pompco Logo
*Systems are customized. Actual components may vary.
**Most common pump size. Other HP available.
